SKU:

M085078

Weight:

10,630.00 Grams

Width:

22.00 (cm)

Height:

23.00 (cm)

Depth:

84.00 (cm)

Shipping:

Calculated at Checkout

Outlet Diameter:

76.66 mm (3.02 inch)

Country Of Origin:

United States

NMFC Code:

125850-08

Gross Height:

9 IN

Gross Length:

33 IN

Gross Volume:

1.4609 FT3

Gross Weight:

21.0404 LB

Gross Width:

8.5 IN

Style:

Style 2

Body Length:

698.5 mm (27.50 inch)

Rated Flow HR:

27.3 m³/min (964 cfm)

Rated Flow LR:

15.8 m³/min (558 cfm)

Rated Flow MR:

22.3 m³/min (788 cfm)

Inlet Diameter:

76.66 mm (3.02 inch)

Overall Length:

812.8 mm (32.00 inch)

Body Diameter Maximum:

214.88 mm (8.46 inch)

Attenuation HR:

22 dBA

Attenuation LR:

18 dBA

Inlet Clock Position:

6:00

Back Pressure Low-Range:

25 mm Hg (0.98 inch Hg)

Back Pressure Mid-Range:

51 mm Hg (2.01 inch Hg)

Back Pressure High-Range:

76 mm Hg (2.99 inch Hg)

Outlet Clock Position:

12:00
