SKU:

A052526

Weight:

7,810.00 Grams

Width:

23.00 (cm)

Height:

56.00 (cm)

Depth:

24.00 (cm)

Shipping:

Calculated at Checkout

Outlet Diameter:

50.8 mm (2.00 inch)

Brand:

Cyclopac™

Country Of Origin:

United States

HTS Code:

8421310052

NMFC Code:

069100-05

Gross Height:

0.45 M

Gross Length:

0.17 M

Gross Volume:

0.0153 M3

Gross Weight:

6.61 LB

Gross Width:

0.2 M

Family:

FWA

Body Length:

302.26 mm (11.90 inch)

Rated Flow HR:

2.6 m³/min (92 cfm)

Rated Flow LR:

2 m³/min (71 cfm)

Rated Flow MR:

2.3 m³/min (81 cfm)

Inlet Diameter:

50.8 mm (2.00 inch)

Overall Length:

431.29 mm (16.98 inch)

Restriction HR:

254 mm H2O (10.00 inch H2O)

Restriction LR:

152 mm H2O (5.98 inch H2O)

Restriction MR:

203 mm H2O (7.99 inch H2O)

Body Diameter Maximum:

133.35 mm (5.25 inch)
