SKU:

A092037

Weight:

28,920.00 Grams

Width:

31.00 (cm)

Height:

41.00 (cm)

Depth:

91.00 (cm)

Shipping:

Calculated at Checkout

Outlet Diameter:

152.4 mm (6.00 inch)

Brand:

Konepac™

Country Of Origin:

United States

HTS Code:

8421310052

NMFC Code:

069100-05

Gross Height:

16 IN

Gross Length:

36 IN

Gross Volume:

4 FT3

Gross Weight:

25.135 LB

Gross Width:

12 IN

Style:

Cone

Family:

EBA

Body Length:

727 mm (28.62 inch)

Rated Flow HR:

32 m³/min (1130 cfm)

Rated Flow LR:

24.8 m³/min (876 cfm)

Rated Flow MR:

28.3 m³/min (999 cfm)

Inlet Diameter:

152.4 mm (6.00 inch)

Overall Length:

766.83 mm (30.19 inch)

Restriction HR:

254 mm H2O (10.00 inch H2O)

Restriction LR:

152 mm H2O (5.98 inch H2O)

Restriction MR:

203 mm H2O (7.99 inch H2O)

Body Diameter Maximum:

228.6 mm (9.00 inch)
