SKU:

A112018

Weight:

40,950.00 Grams

Width:

36.00 (cm)

Height:

50.00 (cm)

Depth:

91.00 (cm)

Shipping:

Calculated at Checkout

Outlet Diameter:

177.8 mm (7.00 inch)

Brand:

Konepac™

Country Of Origin:

United States

NMFC Code:

069100-04

Gross Height:

19.75 IN

Gross Length:

36 IN

Gross Volume:

5.7604 FT3

Gross Weight:

30.45 LB

Gross Width:

14 IN

Style:

Cone

Family:

EBA

Body Length:

727 mm (28.62 inch)

Rated Flow HR:

41.7 m³/min (1473 cfm)

Rated Flow LR:

32.6 m³/min (1151 cfm)

Rated Flow MR:

36.8 m³/min (1300 cfm)

Inlet Diameter:

177.8 mm (7.00 inch)

Overall Length:

767.08 mm (30.20 inch)

Restriction HR:

254 mm H2O (10.00 inch H2O)

Restriction LR:

152 mm H2O (5.98 inch H2O)

Restriction MR:

203 mm H2O (7.99 inch H2O)

Body Diameter Maximum:

279.4 mm (11.00 inch)
