SKU:

B100127

Weight:

30,880.00 Grams

Width:

45.00 (cm)

Height:

61.00 (cm)

Depth:

45.00 (cm)

Shipping:

Calculated at Checkout

Outlet Diameter:

114.3 mm (4.50 inch)

Brand:

Cycloflow™

Family:

XRB

Body Length:

487.3 mm (19.18 inch)

Rated Flow HR:

13.4 m³/min (473 cfm)

Rated Flow LR:

9.34 m³/min (330 cfm)

Rated Flow MR:

11.5 m³/min (406 cfm)

Inlet Diameter:

127 mm (5.00 inch)

Overall Length:

565.3 mm (22.26 inch)

Restriction HR:

254 mm H2O (10.00 inch H2O)

Restriction LR:

152 mm H2O (5.98 inch H2O)

Restriction MR:

203 mm H2O (7.99 inch H2O)

Body Diameter Maximum:

288.5 mm (11.36 inch)
